E57CX

5" x 7" Coaxial Kit

DETAILS

5 x 7 Inch Coaxial Kit –  Aluminum coated injection polypropylene cone with rubber surround powder coated steel basket

SPECIFICATIONS

COAXIAL

  • Free Air Resonance: 61.15 Hz
  • Nominal Impedance: 4 Ohms
  • Sensitivity 2.83 v @ 1 meter: 91.4
  • Outside Diameter: 194 x 133 mm
  • Mounting Hole Diameter: 180 x 127 mm
  • Mount Depth: 61 mm
  • Coaxial Tweeter
  • 4 ohm
  • Integrated 6dB crossover
  • Polyester capacitor
  • Tweeter overload protection
  • Maximum Linear Excursion: ± 4 mm
