Carbon Series 5-Inch 2-Way Component Kit
C5
5" 2-Way Component KitDETAILS
SPECIFICATIONS
MIDBASS
- Free Air Resonance: 83.3 Hz
- Nominal Impedance: 4 Ohms
- Sensitivity 2.83 V @ 1 meter: 87.3
- Outside Diameter: 129 mm basket + 149.2 mm ears
- Mounting Hole Diameter: 120 mm
- Mount Depth: 43.4 mm
- Maximum Linear Excursion: ± 5.5 mm
CROSSOVER
- Bi Amp 12 dB crossover
- Tweeter overload protection
- Dimensions: 131 x 84 x 38 mm
TWEETER
- Component Tweeter
- 25 mm Beryllium Copper
- 4 ohm
- Outside Diameter: 48.2 mm
- Mount Hole: 43.5 mm
- Mount Depth: 24 mm
